Vehicle Lifts - Roll Over Roof

The Space Saver

Park or Play: One up, One down

Safetech roll-over Car Lifts provide extra car parking space on the roof of the lift.
When closed two cars can be accommodated. One on the roof and a second parked below on the lift or driving through to a basement garage.

Download Vehicle Lift Brochure

Roof Separation For Longer Travel

Affordable longer travel is made possible by Safetech’s custom roof design.

Our modular roof can be separated from the lift during descent, making access to deeper basement levels possible.

Locking pins ensure that loads remain safe and secure on the upper level.

See it in Action!

Sensor Array Layout Overview

Safetech ensures that no matter what area configuration you have your property and loved ones will be protected.

Legend
Sensor Array, 300mm from shaft	Horizontal Area Sensor, 350mm-high	Vertical Area Sensor	Laser sensor, 350mm-high	Laser sensor, 1100mm-high	Interlocked Gate	Non-interlocked Gate	Wall, less than 500mm from shaft

Controlled Courtyard
		Surrounding walls more than 1100mm-high
		Walls less than 500mm from shaft
		MACHINE FEATURES
		Gate(s) and doors controlling access into area
		Interlocked doors & gates
		Car doors & walls not required
		1x Horizontal area sensor sensing court-yard is clear prior to table raise
		“Front” (red) sensor array handed near gate operator to simplify wiring

2-Sided Courtyard With Gate
		Walls on 2 sides more than 1100mm-high
		Walls less than 500mm from shaft
		MACHINE FEATURES
		Door & gate interlocking not required
		Car doors & walls required
		2x Vertical area sensors sensing open side & end
		2x PE sensors sensing wall sides
		1x PE sensor sensing courtyard is clear prior to table raise
		“Front” (red) sensor array handed close to wall to avoid obstructing vehicles

2-Sided Courtyard
		Walls on 2 sides more than 1100mm-high
		Walls less than 500mm from shaft
		MACHINE FEATURES
		Gate(s) and doors controlling access into area
		Door & gate interlocking not required
		Gate can be controlled with additional (5th) button on remote (option)
		Car doors & walls required
		3x Vertical area sensors sensing open side & ends
		1x PE sensor sensing wall side
		1x PE sensor sensing courtyard is clear prior to table raise
		“Front” (red) sensor array handed near gate operator to simplify wiring

3-Sided Courtyard
		Walls on 3 sides more than 1100mm-high
		Walls less than 500mm from shaft
		MACHINE FEATURES
		Door & gate interlocking not required
		Car doors & walls required
		2x Vertical area sensors sensing open side & end
		2x PE sensors sensing wall sides
		1x PE sensor sensing courtyard is clear prior to table raise
		“Front” (red) sensor array handed close to wall to avoid obstructing vehicles

Open Courtyard
		No effective walls
		MACHINE FEATURES
		Door & gate interlocking not required
		Car doors & walls required
		4x Vertical area sensors sensing open side & end
		1x PE sensor sensing courtyard is clear prior to table raise
		“Front” (red) sensor array handed to avoid obstructing vehicles
